• Lightweight 700L steel

• Hot dip galvanized

• Black Paint

• Patent Pending 4 Layer insulation with an additional 5th layer of aluminum skin with baked paint on the outside for durability, and resistance.

• Aluminum extrusions all across and aluminum angle on the inside.

• 9 Industrial grade high quality Polyamide thermal break molds to stop any thermal bridging.

• Expedition door and windows made with aircraft grade aluminum with aluminum handles and weatherproof seals.

• Expedition style Safari Hatch with built in windows over the dinning area.

• 7 Windows all around to experience vistas from anywhere in the cabin.

• Expedition door with peek window and mesh screen.

• All windows come with high quality integrated blackout and mesh screen.

• Heavy duty gas struts that allow 90 degree opening of the windows and can be open in rain and wind.

• Windows are integrated with rain fly to avoid water dripping inside when open on a rainy day.

• Sensor enabled staircase that opens upon opening the door. Staircase can be deployed and or retracted on the inside.

• Front and Rear Light Bars

• Twin Passenger and Driver side LED lights.

• Cruisemaster DO45+ Hitch.

• Sliding Outdoor Kitchen on the passenger side with two 120v AC outlets and water connection in the kitchen storage cabinet. Outdoor kitchen features an induction cooktop, prep area, sink, faucet and drain pipe.

• Front ~39” deep storage box with a heavy duty locking large access door up front and 2 heavy duty locking access doors on sides for easy access to smaller items.

• Front slope rain collection pipes on driver and passenger side.

• Heavy duty aluminum rock sliders (optional).

• Aluminum top roof side rails.

• 7000 lb detachable swivel tongue jack.

• 4 Corner Stabilizer Steadies.

• RREV’s signature GRP custom molded rear cowling with integrated 24v DC AC Compressor Condenser, Deployable ladder to the roof with rails, Rear storage box with optional Molle Panel for gear and 33” spare tire holder.

• 13,500 lbs rear winch.

• Twin Bike Rack Mounts.

• Rear recovery points with 11,000 lbs rated bars and fully forged 9Ton WLL shackles.

• Custom 65 Gallon Stainless Steel General Water Tank with baffles, independent water pump and usage. Marine style pickup tube for maximum water usage.

• Custom 26 Gallon Stainless Steel Buffer Tank with baffles, independent pump and usage. Marine style pickup tube for maximum water usage.

• Truma Combi Diesel Water Heater.

• 27 Gallon Gray Water Tank.

• All the plumbing and tanks (except gray tank) are inside therefore no problems with extreme cold.

• RREV’s proprietary system, HUB, integrating all energy systems - solar, shore and tow vehicle charging, battery bank, inverter, lighting, bathroom vent fan, steps and more.

• 24v 400 AH Lithium Battery Bank featuring smart BMS integrated with RREV’s HUB system. Upgradeable to 800AH.

• Samsung Android Touch Screen Control Panel (standard). Can option for an Apple iPad.

• Three high quality 52v | 450W rigid solar panels wired in series for faster charging. Upgradeable to 4 x 450W.

• HUB integrated 2400W 24v Victron Energy MPPT Solar Charger.

• RREV HUB integrated 3000W 24v | 120V | 70 Amp Victron Energy Inverter Charger.

• RREV HUB integrated 50A DC DC Charger with 50A Andersen plug at the tongue ready to connect to the tow vehicle.

• RREV HUB integrated 50A Andersen connection for additional portable Solar Charging.

• Multiple 120V outlets inside and outside the camper.

• 12v/24v USB outlets with fast charging. 12v step down with busbar for additional 12v connections.

• Blue Sea Systems 30A AC MAIN with reverse polarity and 4 position distribution panel with First Defense Surge Protector prewired..

• Victron Energy 1000 Amp distributor with Mega Fuses and Fuse Panel.

• RREV HUB app for web, Android and iOS with local access. Secure remote access is free for first 2 years of ownership and then $65/yr afterwards.

• Fridge:

• 230L DC fridge with 5 temperature settings and Night mode for a quieter operation.

• Anti-vibration and off road ready locking mechanisms.

• Black Color.

• Furrion 0.9 cu.ft. RV Microwave Oven (Optional)

• Furrion Electric Oven (Optional):

• Furrion Chef Collection's built in electric (120v) oven.

• 2.0 cu.ft oven capacity

• Fan assist & broil function

• Triple layer glass door

• Vibrationsmart designed for vibration resistance

• Climatesmart tested for extreme climates

•  Induction Cooktop:

• Twin burner induction cooktop.

• Full glass with touch screen buttons.

• Safe cooking feature

• 9 temperature settings

• Optional Microwave/Air Fryer Inbuilt

• Dry Weight: ~6,300 lbs (Tandem). +450 lbs (Triple)

• Tongue Weight: ~630 lbs. (adjustable. with air suspension).

• GVWR: 10,000 lbs.

• Suspension: 14,500 lbs (Tandem) 17,000 (Triple)

• Heavy Duty 13,000+ lbs (Tandem standard) rated in-house engineered RREV Independent Suspension Swing Arm (ISA) suspension. Triple configuration is optional.

  • Built with HD DOM Tubing

  • Buckling Load Rating of 18, 550 N

  • 4,300+ lbs Load Capacity per Arm

• 4 Air Springs with aluminum base, inbuilt bump stops and ARB Shocks. Optional King Shocks available.

• Bluetooth Low Energy (BLE) to the Air Suspension controlled via an app with a few important functions:

• Independent control of all 4 wheels (great for off-roading and leveling).

• Airing up and down all the springs at once.

• Independent control of front and rear 2 wheels (great for changing tires or running on a single axle).

• Up to 3 presets so you can preprogram what pressure you want for freeway, off road etc. Also great for hitching unhitching.

• Load sharing and terrain based full time auto leveling (optional).

• 24v ARB Twin Compressor.

• Five Solid A356 aluminum with T6 heat treatment construction 16” MATTE BLACK Method Wheels..

• Five 33” Mickey Thompson Boss Baja A/T Tires.

• Hydrualic Disc Brakes with 1,600 psi Hydrastar actuator.

• Oil bath hubs and bearings with little to zero maintenance.

• 10,000 lbs rated webbed limit strap on each swing arm.

iNet Ready Truma Combi Diesel Heater for air and water heating.

Ducted heating with outlets -  towards the alley and in the bathroom.

Custom made 24v DC | 11,000 BTU Air Conditioner

Automotive grade R134a cooling agent for easy recharge if and when needed

-20F to 120F

• Outside Storage:

• Driver side access cabinet with heavy duty weatherproof locking door.

• Massive front storage box with 3 heavy duty weatherproof locking doors.

• Inside Storage:

• Kitchen: 4 Overhead Cabinets, 1 large Storage Cabinet (when oven is not optioned), 3 sliding drawers, Under the sink and near floor storage with access doors.

• Bed: 4 overhead cabinets, 2 side closets, 2 bedside lift door cabinets, 1 bottom drawer and 2 bedside pockets. Large under the bed storage space with a hatch.

• Dinette: 3 overhead cabinets, 2 under the dinette near floor drawers.

• Bathroom: 3 overhead cabinets, 2 top shelves, 3 under the countertop shelves, 1 drawer and 2 storage space with doors.

• All doors are locked with aluminum locking handle so on and off road stowing.

• Standard Casette Toilet.

• OGO Composting Toilet (Optional).

• Tiny Separatt (Optional)

• Cinderella Incinerator Toilet (Optional)

Cruisemaster DO35 Hitch with 360 degrees of articulation.

• Track Width: 72”.

• 20.8′ Box | 27′ Long | 7.3′ Wide.

• Height is adjustable (Air suspension).

Given this is a new model, 5-6 months but current lead times may vary down the line.

15 years frame.

2 years craftsmanship

Applicable appliance manufacturers warranty for equipment.
