Lightweight 700L steel

Hot dip galvanized

Black Paint

Patent Pending 4 Layer insulation with an additional 5th layer of aluminum skin with baked paint on the outside for durability, and resistance.

Aluminum extrusions all across and aluminum angle on the inside.

9 Industrial grade high quality Polyamide thermal break molds to stop any thermal bridging.

Expedition door and windows made with aircraft grade aluminum with aluminum handles and weatherproof seals.

Expedition door with peek window and mesh screen.

All windows come with high quality integrated blackout and mesh screen.

Heavy duty gas struts that allow 90 degree opening of the windows and can be open in rain and wind.

Sensor enabled staircase that opens upon opening the door. Staircase can be deployed and or retracted on the inside.

Front and Rear Strands Siberia Light Bars

Twin Passenger and Driver side LED lights.

Cruisemaster DO35 Hitch.

RREV’s signature GRP custom molded rear cowling with integrated 24v DC AC Compressor Condenser, Deployable ladder to the roof with rails, Rear storage box with optional Molle Panel for gear and 33” spare tire holder.

9,000 lbs rear winch.

Twin Bike Rack Mounts.

Rear recovery points with 11,000 lbs rated bars and fully forged 9Ton WLL shackles.

50 Gallon freshwater tank, pressurized system, optional filtration kit.

26 Gallon Gray Tank.

No Black tank.

RREV’s proprietary system, HUB, integrating all energy systems - solar, shore and tow vehicle charging, battery bank, inverter, lighting, bathroom vent fan, steps and more.

24v 280 AH Lithium Battery Bank featuring smart BMS integrated with RREV’s HUB system. Upgradeable to 800AH.

Samsung Android Touch Screen Control Panel (standard). Can option for an Apple iPad.

Twohigh quality 52v | 400W rigid solar panels wired in series for faster charging.

HUB integrated 24v Victron Energy MPPT Solar Charger.

RREV HUB integrated 2000W 24v | 120V | 30 Amp Victron Energy Inverter Charger.

RREV HUB integrated 50A DC DC Charger with 50A Andersen plug at the tongue ready to connect to the tow vehicle.

Multiple 120V outlets inside and outside the camper.

12v/24v USB outlets with fast charging. 12v step down with busbar for additional 12v connections.

Custom RREV Distribution Panel with micro-chip breakers

Victron Energy distributor with Mega Fuses and Fuse Panel.

RREV HUB app for web, Android and iOS with local access. Secure remote access is free for first year of ownership and then $65/yr afterwards.

Fridge:

100L DC fridge.

Furrion Electric Oven (Optional):

Furrion Chef Collection's built in electric (120v) oven.

2.0 cu.ft oven capacity

Fan assist & broil function

Triple layer glass door

Vibrationsmart designed for vibration resistance

Climatesmart tested for extreme climates

Induction Cooktop:

Twin burner induction cooktop.

Full glass with touch screen buttons.

Safe cooking feature

9 temperature settings

Optional Microwave/Air Fryer Inbuilt

Dry Weight: ~3,700 lbs.

Tongue Weight: ~395 lbs

GVWR: 6,000 lbs.

Suspension:9,000 lbs

Heavy Duty 9,000+ lbs rated in-house engineered RREV Independent Suspension Swing Arm (ISA) suspension.

• Built with HD DOM Tubing

• Buckling Load Rating of 18, 550 N

• 4,300+ lbs Load Capacity per Arm

 Air Springs with aluminum base, inbuilt bump stops and ARB Shocks with remote reservoir.

Bluetooth Low Energy (BLE) to the Air Suspension controlled via an app with a few important functions:

- Independent control left-right (great for off-roading and leveling).

- Airing up and down all the springs at once.

- Up to 3 presets so you can preprogram what pressure you want for freeway, off road etc. Also great for hitching unhitching.

- Load sharing and terrain based full time auto leveling (optional).

- 24v ARB Twin Compressor.

3 Solid A356 aluminum with T6 heat treatment construction 16” MATTE BLACK Method Wheels..

Three 33” Mickey Thompson Boss Baja A/T Tires.

Hydrualic Disc Brakes actuator.

Oil bath hubs and bearings with little to zero maintenance.

10,000 lbs rated webbed limit strap on each swing arm.

iNet Ready Truma Combi Diesel Heater for air and water heating.

Ducted heating with outlets -  towards the alley and in the bathroom.

Custom made 24v DC | 11,000 BTU Air Conditioner

Automotive grade R134a cooling agent for easy recharge if and when needed

-20F to 120F

Outside Storage:

Driver side access cabinet with heavy duty weatherproof locking door.

Inside Storage:

Kitchen: Overhead Cabinets, 1 large Storage Cabinet (when oven is not optioned), sliding drawers, Under the sink and near floor storage with access doors.

Bathroom: 3 overhead cabinets, 2 top shelves, 3 under the countertop shelves, 1 drawer and 2 storage space with doors.

All doors are locked with aluminum locking handle so on and off road stowing.

Standard Casette Toilet.

OGO Composting Toilet (Optional).

Cruisemaster DO35 Hitch with 360 degrees of articulation.

Track Width: 72”.

Height is adjustable (Air suspension).

Box Space 15.5’

Overall Length 18.5’

Given this is a new model, 4-5 months but current lead times may vary down the line.

15 years frame.

2 years craftsmanship

Applicable appliance manufacturers warranty for equipment.
